E-Vocal Stage is a Multi-Channel Dante Converters.
E-Vocal Stage Series are the converters designed to transfer 16 audio channels over a Dante network in both directions. Two etherCON connectors (Dante Primary/Secondary) are available for redundant operation using two separate networks. For high availability operation requirements, dual AC input and dual PoE power sources are available for redundant operation. This robust and portable unit is designed to be placed horizontally or vertically on stage, providing impeccable integration and ability to endure harsh live performance environment. Any other settings, such as sampling frequency, channel routing or latency, can be made by the free “Dante Controller” computer application. ARS-1616S-A10 also featured with Preamp (phantom Power), gain control and mute functions.
-
- Convert 16 channels of analog Mic/Line input signals to a Dante ® network
- Converts a Dante ® stream into 16 channels of analog output signals
- Control Mute
- Adjustable Gain Control Preamp (-8dB to +34dB) with Phantom Power
- Two LAN etherCON connectors for primary and secondary networks provide redundancy
- Supports long distance audio signal transmission over optical fiber network interface
- Up to 96 kHz sampling rate and 24 bit resolution
- Dual AC input and dual PoE power sources
- Built-in web-based controller for monitoring unit operation status via web browser
-
Model Name ARS-1616S-A00 ARS-1616S-A10 PRODUCT SPECIFICATIONS Function 16Ch Analog Input
16Ch Analog Output16Ch Analog Input
16Ch Analog OutputMute NA YES Preamp NA YES Phantom Power NA YES Max Signal Level (Balanced) +24dBu / +4dBu / 0dBu, 0dBV /-10dBV
+18dBu / +4dBu / 0dBu, 0dBV /-10dBVFrequency Response 20Hz to 20kHz (-/+0.5dB) Impedance 20k Ohm balanced, 10k Ohm unbalanced
150 Ohm balanced, 75 Ohm unbalancedDynamic Range ﹥ 100dB Signal to Noise Range ﹥ 100dB Total Harmonic Distortion ﹤ 0.01% at +4dBu Mic PreAmp NA Lip-Sync Delay NA AC Power Dual 110-220VAC PoE Dual 802.3at PoE Sample Rates 44.1, 48, 96 kHz Bit Depths 24 Dante Device Latency 1, 2, or 5ms (configurable using Dante Controller Network Transport Dante Audio over IP, AES67 RTP (Dual RJ45 or Singlemode SFP/Multimode SFP) -
APP-1600
Rack mounted I/O panel with 16x XLR Female to 2x DB25 rear connections.
APP-0808
Rack mounted I/O panel with 8x XLR/TRS combo jack and 8x XLR Male to 2x DB25 rear connection.
APP-0016
Rack mounted I/O panel with 16x XLR Male to 2x DB25 rear connections.
8 Channel XLR Female Snack Cable
8 Channel XLR Male Snack Cable
25 Pin D Sub to 25 Pin D Sub Cable
-
Description
E-Vocal Stage is a Multi-Channel Dante Converters.
E-Vocal Stage Series are the converters designed to transfer 16 audio channels over a Dante network in both directions. Two etherCON connectors (Dante Primary/Secondary) are available for redundant operation using two separate networks. For high availability operation requirements, dual AC input and dual PoE power sources are available for redundant operation. This robust and portable unit is designed to be placed horizontally or vertically on stage, providing impeccable integration and ability to endure harsh live performance environment. Any other settings, such as sampling frequency, channel routing or latency, can be made by the free “Dante Controller” computer application. ARS-1616S-A10 also featured with Preamp (phantom Power), gain control and mute functions.
-
Features
- Convert 16 channels of analog Mic/Line input signals to a Dante ® network
- Converts a Dante ® stream into 16 channels of analog output signals
- Control Mute
- Adjustable Gain Control Preamp (-8dB to +34dB) with Phantom Power
- Two LAN etherCON connectors for primary and secondary networks provide redundancy
- Supports long distance audio signal transmission over optical fiber network interface
- Up to 96 kHz sampling rate and 24 bit resolution
- Dual AC input and dual PoE power sources
- Built-in web-based controller for monitoring unit operation status via web browser
-
Technical Spe.
Model Name ARS-1616S-A00 ARS-1616S-A10 PRODUCT SPECIFICATIONS Function 16Ch Analog Input
16Ch Analog Output16Ch Analog Input
16Ch Analog OutputMute NA YES Preamp NA YES Phantom Power NA YES Max Signal Level (Balanced) +24dBu / +4dBu / 0dBu, 0dBV /-10dBV
+18dBu / +4dBu / 0dBu, 0dBV /-10dBVFrequency Response 20Hz to 20kHz (-/+0.5dB) Impedance 20k Ohm balanced, 10k Ohm unbalanced
150 Ohm balanced, 75 Ohm unbalancedDynamic Range ﹥ 100dB Signal to Noise Range ﹥ 100dB Total Harmonic Distortion ﹤ 0.01% at +4dBu Mic PreAmp NA Lip-Sync Delay NA AC Power Dual 110-220VAC PoE Dual 802.3at PoE Sample Rates 44.1, 48, 96 kHz Bit Depths 24 Dante Device Latency 1, 2, or 5ms (configurable using Dante Controller Network Transport Dante Audio over IP, AES67 RTP (Dual RJ45 or Singlemode SFP/Multimode SFP) -
Ordering Info.
-
Accessories
APP-1600
Rack mounted I/O panel with 16x XLR Female to 2x DB25 rear connections.
APP-0808
Rack mounted I/O panel with 8x XLR/TRS combo jack and 8x XLR Male to 2x DB25 rear connection.
APP-0016
Rack mounted I/O panel with 16x XLR Male to 2x DB25 rear connections.
8 Channel XLR Female Snack Cable
8 Channel XLR Male Snack Cable
25 Pin D Sub to 25 Pin D Sub Cable
