AVC-100-HS
SDI HDMI Video Converter
-
Arista AVC-100 Series is a video converter for SD/HD/3G-SDI to HDMI or HDMI to SD/HD/3G-SDI, up to 1080p. Using the AVC-100 series converter. Different formats video signal will be converted for SD/HD/3G-SDI with audio and HDMI format. It is an easy way to give your old computer an inexpensive upgrade or make it backwards compatible with legacy systems.
-
- Auto detect signal soure, supports OSD(on Screen Display)
- Support HDMI output: up to 1080P/60Hz
- Plug and Play
- Easy to install
- No software easy to operate
-
Model Name AVC-100-SH AVC-100-HS PRODUCT SPECIFICATIONS Role of Usage Video converter Video resolution Up to 1920 x 1080 Input 1 x SD/HD/3G-SDI 1 x HDMI Output 1 x HDMI, 1 x SD/HD/3G-SDI Loop-Back 2 x SD/HD/3G-SDI HDMI connector HDMI 19 pin female BNC connector BNC female Mounting Wall mount Physical Dimension
(W x H x D)3.30 x 3.90 x 1.10 inch
84.2 x 99.4 x 28.2 mmPower/Thermal Specs Power supply 9~32V DC Power input Power Consumption 3 W Recommended Power 5 W Heat Dissipation 11 BTU/hr Environmental Operation Temperature 0~50°C (32~122°F)) Storage Temperature -20~60°C (-4~140°F) Relative Humidity 0~95% -
Ordering Information AVC-100-SH AVC-100-HS Type SDI to HDMI converter HDMI to SDI converter
-
Description
Arista AVC-100 Series is a video converter for SD/HD/3G-SDI to HDMI or HDMI to SD/HD/3G-SDI, up to 1080p. Using the AVC-100 series converter. Different formats video signal will be converted for SD/HD/3G-SDI with audio and HDMI format. It is an easy way to give your old computer an inexpensive upgrade or make it backwards compatible with legacy systems.
-
Features
- Auto detect signal soure, supports OSD(on Screen Display)
- Support HDMI output: up to 1080P/60Hz
- Plug and Play
- Easy to install
- No software easy to operate
-
Technical Spe.
Model Name AVC-100-SH AVC-100-HS PRODUCT SPECIFICATIONS Role of Usage Video converter Video resolution Up to 1920 x 1080 Input 1 x SD/HD/3G-SDI 1 x HDMI Output 1 x HDMI, 1 x SD/HD/3G-SDI Loop-Back 2 x SD/HD/3G-SDI HDMI connector HDMI 19 pin female BNC connector BNC female Mounting Wall mount Physical Dimension
(W x H x D)3.30 x 3.90 x 1.10 inch
84.2 x 99.4 x 28.2 mmPower/Thermal Specs Power supply 9~32V DC Power input Power Consumption 3 W Recommended Power 5 W Heat Dissipation 11 BTU/hr Environmental Operation Temperature 0~50°C (32~122°F)) Storage Temperature -20~60°C (-4~140°F) Relative Humidity 0~95% -
Ordering Info.
Ordering Information AVC-100-SH AVC-100-HS Type SDI to HDMI converter HDMI to SDI converter -
